| Unit of measurement | Iso-V EC 315 | |
| Phases | - | 1 |
| Minimum supply voltage | V | 200 |
| Maximum supply voltage | V | 240 |
| Power supply frequency | Hz | 50/60 |
| Maximum airflow | m³/h | 2370 |
| Weight | kg | 25.7 |
| Transported air temperature (max) | °С | 80 |
| Transported air temperature (min) | °С | -40 |
| Ingress protection rating | - | IPX4 |
| Impeller material | - | Plastic |
| Trademark | Blauberg |
| Model | Iso-V EC 315 |
| Type of ventilation unit | Unidirectional |
| Type of drive installed | Integrated VSD |
| Type of heat recovery system | None |
| Nominal external pressure (Pa) | 223 |
| Maximum external leakage rates (%) | 2.7 |
| Static efficiency (%) | 70.2 |
| Declared typology | NRVU UVU |
| Effective electric power input (kW) | 0.15 |
| Sound power level (dB(A)) | 55 |
| A |
|---|
| 500 |
